Features:
Infrared optical detection technology
Automatically scanning blood and location of the plasma interface from time to time with accurate positioning
Internal thermal printeEr SR curve display and print-out
Automatically adjusting the ESR results under the detecting temperature (15.C -32.C) to the ESR values ​​at 18 ℃ closely related with Westergren results
The results are not interfered by as jaundice hemolysis or chyle

Specifications:
Measuring principle Infrared barrier
Measuring time 30 minutes
Measuring precision <0.2 mm
Reproducibility <3%
Temperature Precision <0.3 ℃
Sample volume <1.6mL whole blood anticoagulant
Reading channel 10
Display LCD screen with backlight
RS-232 serial port interface
Print Internal thermal recorder
Operation conditions Temperature 15 ℃ ~ 32 ℃
Humidity≤85%
Power supply AC 220V / 110V ± 10%, 50/60 Hz
Dimension 320mmx260mmx158mm (LxWxH)
Netweight 5kg
