- description
| Microscope |
Type | Galileo parallel style super optic | |
| Magnification change |
Five magnification |
||
| Eyepiece | 12.5x | ||
| Total magnification |
6x 10x 16x 25x 40x |
||
| Field of View | 6X: 33mm, 10X: 20mm, 16X: 13mm, 25X: 8mm, 40X :5mm | ||
| Range of adjusting the distance of pupil |
55 mm-75 mm | ||
| Range of adjusting eyepieces |
-8D - +8D | ||
|
|
||
| Slit length |
1mm-14mm | ||
| Diameter of aperture |
φ14mm,φ10mm,φ5mm,φ2mm,φ1mm,φ0.2mm | ||
| Slit angle | 0-180 | ||
| Illumination angle |
0, 5, 10, 15, 20 | ||
| Filter | Heat absorption, Grey, red free(Green), Cobalt blue | ||
| Bulb | 12v, 50w halogen bulb | ||
| Moving |
Forward and backward moving |
90mm | |
| Left and right moving |
100mm | ||
| Handle moving | 15mm | ||
| Up and down moving |
30mm | ||
| Jaw bracket part | Up and down moving |
80mm | |
| Fixation | Red LED | ||
| Power |
Input voltage | 110/220V±10％ | |
| Input frequency | 50/60Hz | ||
| Input power | 60VA | ||
| Output voltage |
Illumination: 4.5V 9V 12V Fixation: 6V |
||
| Safe standard of electric | IEC601－1, type Ⅰof BF Model | ||
| Weight and Dimension |
Packing box | 720mmx495mmx480mm | |
| Gross weight | 25Kg | ||
| Net weight | 21Kg |
système de stockage de cas spécial
fonction professionnelle d'analyse et de traitement d'images
éclairage du flash (option)
système d'éclairage de fond
vidéo haute définition
système super optique
oculaire de définition supérieure
Poignée multifonction (vous pouvez régler l'éclairage par la poignée) Option
