Le détail de l’article

Temps réel: Type en temps réel

Bloc thermique
Sample capacity(wells)	48
Reaction Volume	5-100 μL
Consumables	0.2ml 8-strip tubes ,0.2ml PCR single tube(Optical flat cap,clear tube)
Temperature range	0°C-100°C
Heating/cooling method	Peltier
Max heating rate	8.0°C/sec
Average heating rate	6.0°C/sec
Max cooling rate	5.5°C/sec
Average cooling rate	4.0°C/sec
Temperature accuracy	±0.1℃
Temperature uniformity	±0.1℃
Gradient Range	1°C-40°C
Gradient block	8 row
Special temperature portocol	Gradient PCR,Long PCR,Touch Down PCR
Heat Lid
Temperature range	Room Temperature–110°C
Optical System
Excitation Source	4LEDs
Detector	Photodiode
Detection Position	Excitation and scan from lateral
Detection method	4 channels scanning at the same time, no edge effect.
Detection time	2 seconds for 48 wells for all channels
Range of excitation/ emission wavelengths (nm)	1 465 /510 (FAM,SYBR Green I，SYTO9，EvaGreen，LC Green) 2 527/ 563 (HEX,VIC,TET,JOE) 3 580 /616 (ROX,Texas Red) 4 632/ 664( Cy5)
Probe	Taqman Probe,Molecular beacons probe，Scorpion probe
Multiplexing	Up to 4 targets
Fluorescence Linearity	r≥0.990
Fluorescence Dynamic Range	Adjustable
Performance
Sample Linearity	/r/≥0.999
Sample repeatability	Ct value CV≤0.5%
Sample Dynamic Range	1-1010 copies
Software Funtions
Data Analysis modes	Qualitative analysis,Absolute quantification, Relative quantification,Genotyping analysis,Endpoint analysis，Melt curve analysis, High Resolution Melting
Control modes	1.7 touch screen 2. PC direct control 3. WLAN control(One PC can control max 10 units, and device can be controled by any PC in the WLAN)
Data Stroage	Upload and download through USB disk,1000 results can be stored in machine
Power failure protection	Automaticly start running experiments after power supply, no need wait PC software
Customize Report	Templetes reserved ,report can customized
Administration Management	Administrator can set funtions limts for users
Fault Management	Fault report and analysis, solution instruction
LIS connection	CSV,Excel,TXT format data output,open port for LIS connection
Others
PC operating system	Win 7, Win 10
Communication Port	1 ethernet and 2 USB
Footprint(WxDxH)	260mm X 400mm X 2605mm
Weight	11kg
Power usage	AC 100 to 125 V / 200 to 240 V (50/60 Hz).
power consumption	600VA
Work environment	Tempereture:10°C~30°C Humidity:20%~85%
